ZWIN-EC06 Online Odor Monitor

ZWIN-EC06 Online Odor Monitor

Air Quality Gas Products 55 0

The ZWIN-EC06 odor online monitor is a new type of analyzer that the company has used for many years of atmospheric environment monitoring experience, and is a new type of analyzer that has been continuously upgraded and improved in combination with industry testing standards. It can be applied to various outdoor odor environment monitoring, including urban atmospheric environment monitoring, industrial park environmental monitoring, garbage disposal plant environmental monitoring, first traffic environmental monitoring, scenic park environmental monitoring, and construction site odor monitoring applications.

ZWIN-EC06 Online Odor Monitor



Product Introduction

The ZWIN-EC06 odor online monitor is a new type of analyzer that the company has used for many years of atmospheric environment monitoring experience, and is a new type of analyzer that has been continuously upgraded and improved in combination with industry testing standards. It can be applied to various outdoor odor environment monitoring, including urban atmospheric environment monitoring, industrial park environmental monitoring, garbage disposal plant environmental monitoring, first traffic environmental monitoring, scenic park environmental monitoring, and construction site odor monitoring applications.

The sampling method of the odor online monitor product is the pump-suction principle. The ZWIN-EC06 Standard products have built-in basic gas detection sensors ranging from four to eight gases , each of which can detect specific malodorous gas . This product can detect up to 8 or more different gases at the same time. It can respond quickly while ensuring the accuracy and continuity of monitoring data, providing data analysis and early warning functions for managers. Not only can it basically meet the gas pollution detection requirements of the industry standard, but also meet the standards of governments.



Technical data



Measuring Data Chemical formula Range Resolution Measuring principle
Odor OU 0-1000 OU 1 electrochemistry
Ammonia NH3 0-100ppm/0-1 0ppm 0.01ppm electrochemistry
hydrogen sulfide H2S 0-100ppm/0-1 0ppm 0.01ppm electrochemistry
VOC(volatile organic compounds) TVOC 0-100ppm/0-1 0ppm 0.001ppm PID
methyl sulfide C2H6S 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
Methyl mercaptan CH4S 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
Dimethyldisulfide C2H6S2 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
carbon disulfide CS2 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
Styrene C8H8 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
Trimethylamine C3H9N 0-100ppm/0-1 0ppm 0.01ppm electrochemistry/PID
temperature - -40℃~80℃ 0.1℃ Sensor
humidity - 0-100%RH 0.1%RH Sensor
Pressure - 300~1100hpa 0.1hpa resistance
Wind direction - 0~360° Mechanical
Wind speed - 0~40 m/s 0.1 m/s Mechanical



Features:

1.The equipment is technically reliable; it adopts highly sensitive sensors and advanced processor technology, with fast response speed, high measurement accuracy and good stability.

2.The device has a built-in temperature regulator to ensure the stable operation of the system.

3.Built-in wireless transmission module and wired transmission module, which can support data docking platform in two modes. It can support multi-platform data docking at the same time.

4.It can support remote upgrade program, modify device number, modify platform docking IP and other functions.

5.The built-in long-life air pump can realize 24-hour continuous operation and automatic monitoring.

6.Monitoring data display; LCD display touch screen is embedded in the product to realize  real-time display and release of monitoring data; at the same time, data interface is also provided for users to access various display screens.

7.Alarm processing; support disconnection alarm, out-of-standard alarm, and abnormal situation alarm; alarm information can be released through sound and light alarms, display screens, or sent to designated mobile phones through text messages.

8.Local storage; the system can support local storage of monitoring data for at least six months.

9.Strong scalability; various monitoring and sensing components can be added or removed according to user requirements. It can be equipped with a locator; it can be equipped with a surveillance camera to realize the fusion transmission of monitoring data and surveillance video.

10.Optional solar power supply; solar power or mains power supply can be used.
