The digital turbidity sensor is an instrument used to measure the concentration of suspended particles in water samples. Usually these particles may be composed of sediment, microorganisms, algae or other organic or inorganic substances, which affect the transparency of water, It works based on the principle of light scattering. The sensor emits light through the water sample, and the suspended particles in the water sample scatter the light. By measuring the intensity of the scattered light, the turbidity of the water sample can be calculated.

Application fields: used in water quality monitoring, water treatment, food processing, environmental monitoring and other fields.

1.Measurement principle: scattering method;

2.Measuring range: turbidity  0~4000NTU;

3.Suspended solids (SS): 0~8000mg/L;

4.Accuracy:<5%;

5.Resolution: 0.01NTU; 0.01mg/L;

6.Repetition rate:<0.1 NTU;

7. Drift: <0.3NTU;

8.Temperature compensator error:< 0.1NTU

9. Response time: <15s;

10.Working temperature: 0-50°C;

11.Sensor size (DXL): ф34X225;

12. Housing material: titanium alloy;

13.Protection level: lP68, 6bar.
